STEVAL-MKI245KA

Name: STMICROELECTRONICS STEVAL-MKI245KA
Brand: STMICROELECTRONICS
SKU: 4457556
Availability: InStock

演示板、ISM330BX、6 轴陀螺仪和加速计

图片仅用于图解说明，详见产品说明。

制造商产品编号STEVAL-MKI245KA复制

库存编号4457556

您的零件号

技术数据表

Data Sheet

5 有货

11 您现在可以预订货品了

5 件可于 5-6 个工作日内送达(英国库存)

数量	价钱 (含税)
1+	CNY242.260 (CNY273.7538)

包装规格：每个

最低: 1

多件: 1

CNY242.26 (CNY273.75 含税)

品項附註

备注

此订单的信息已添加到您的订单确认邮件、发票和发货通知中。

STEVAL-MKI245KA is an ISM330BX evaluation kit based on a 6-axis IMU with wide bandwidth, low-noise accelerometer, embedded sensor fusion and AI for industrial applications. This board is a kit made up of an ad hoc PCB, mounting ISM330BX 6-axis IMU, which is connected through flat cable to a generic adapter board (STEVAL-MKIGI06A) to make it compatible with STEVALMKI109V3. The presence of this square PCB ensures to put sensor board on system to be measured. The device ISM330BX is soldered exactly in centre of board. The STEVAL-MKIGI06A can be plugged into a standard DIL 24 socket. The kit provides complete ISM330BX pin-out and comes ready to use with required decoupling capacitors on VDD and VDDIO power supply lines. This adapter is supported by STEVAL-MKI109V3 motherboard which includes high-performance 32bit MCU functioning as bridge between sensor and PC on which it is possible to use downloadable graphical user interface or dedicated software routines for customized applications.
- User friendly ISM330BX board
- Complete ISM330BX pinout for a standard DIL 24 socket
- Fully compatible with and STEVAL-MKI109V3 motherboards
