TMDSDSK6713 .
TMS320C6713, DSP, CCSTUDIO, STARTER KIT
Image is for illustrative purposes only. Please refer to product description.
ManufacturerTEXAS INSTRUMENTS
Manufacturer Part NoTMDSDSK6713 .Copy
Order Code2342631
Product RangeTUK SGACK902S Keystone Coupler
Your Part Number
No Longer Stocked
Product Information
ManufacturerTEXAS INSTRUMENTS
Manufacturer Part NoTMDSDSK6713 .Copy
Order Code2342631
Product RangeTUK SGACK902S Keystone Coupler
Silicon ManufacturerTexas Instruments
No. of Bits32bit
Silicon Family NameTMS320C67xx
Core ArchitectureC6000
Core Sub-ArchitectureARM9 / DSP
Silicon Core NumberTMS320C6713
Kit ContentsDev Board C6713, Code Composer Studio, USB Cable, Power Supply & Cords, Documents, Software
Product RangeTUK SGACK902S Keystone Coupler
SVHCNo SVHC (27-Jun-2018)
Product Overview
The TMS320C6713 DSP Starter Kit is a low-cost development platform designed to speed the development of high precision applications based on TI´s TMS320C6000 floating point DSP generation. The kit uses USB communications for true plug-and-play functionality.
- Embedded JTAG support via USB
- High-quality 24-bit stereo codec
- Four 3.5mm audio jacks for microphone, line in, speaker and line out
- 512K words of Flash and 16 MB SDRAM
- Expansion port connector for plug-in modules
- On-board standard IEEE JTAG interface
- +5V universal power supply
- A complete Integrated Development Environment (IDE)
- DSP/BIOS real-time kernel, Target error recovery software
- "Plug-in" ability for third-party software for additional functionality
Applications
Embedded Design & Development, Audio, Medical, Communications & Networking, Embedded Design & Development
Contents
C6713 Development Board, USB Cable, Power Supply
Technical Specifications
Silicon Manufacturer
Texas Instruments
Silicon Family Name
TMS320C67xx
Core Sub-Architecture
ARM9 / DSP
Kit Contents
Dev Board C6713, Code Composer Studio, USB Cable, Power Supply & Cords, Documents, Software
SVHC
No SVHC (27-Jun-2018)
No. of Bits
32bit
Core Architecture
C6000
Silicon Core Number
TMS320C6713
Product Range
TUK SGACK902S Keystone Coupler
Technical Docs (1)
Legislation and Environmental
Country of Origin:
Country in which last significant manufacturing process was carried outCountry of Origin:United States
Country in which last significant manufacturing process was carried out
Country in which last significant manufacturing process was carried outCountry of Origin:United States
Country in which last significant manufacturing process was carried out
Tariff No:84733020
RoHS Compliant:Yes
RoHS
RoHS Phthalates Compliant:Yes
RoHS
SVHC:No SVHC (27-Jun-2018)
Download Product Compliance Certificate
Product Compliance Certificate
Weight (kg):1.26779
